HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw

(No reviews yet) Write a Review
SKU:
JT-413452
Availability:
Please Allow 2-3 Days Processing and 1-7 Days Shipping.
  • HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw
  • HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw
  • HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw
  • HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw
  • HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw
  • HVBS-710G, 7" x 10-1/2" Horizontal/Vertical Mitering Geared Head Bandsaw

Description

JET Mitering Horizontal bandsaws unique design features a swiveling head while the base remains stationary. This allows the stock to remain same position while making accurate crosscuts and miters. Backed by the industry leading two year warranty, JET Mitering Bandsaws are built to last and deliver precision results.

FEATURES

  • Mitering head swivels to cut any angle 0° - 45° while the work piece remains secured
  • Hardened and ground drive shaft and worm gears transmit maximum torque to blade wheels
  • Fully adjustable hydraulic downfeed system
  • Heavy-duty cast iron saw bow and bed
  • Large 8" wheels and handle for easy movement
  • Quick-positioning vise with fully adjustable jaws
  • Built-in, self propelled blade brush extends blade life
  • Vertical work table
  • Coolant system
  • Adjustable material stop
  • 3/4" Bi-Metal blade

SPECIFICATIONS

  • Cutting Capacity (W x D) (In.) 7 x 10-1/2
  • Round at 45 Degrees (In.) 4
  • Round at 90 Degrees (In.) 7
  • Rectangle at 45 Degrees (In.) 4-3/4 x 4
  • Rectangle at 90 Degrees (In.) 7 x 10-1/2
  • Vise Swivels (Deg.) 45°
  • Head Movement (Deg.) 45°
  • Blade Size (In.) 3/4 x .035 x 93
  • Blade Length (In.) 93-5/8
  • Blade Wheel Diameter (In.) 11-3/4
  • Blade Speed (SFPM) 145, 200, 245
  • Bed Height (In.) 23
  • Drive Geared Head
  • Motor (HP) 1 HP, 115/230V, 1Ph
  • Prewired Voltage (V.) 115
  • Overall Dimensions (L x W x H) (In.) 51 x 22-1/2 x 41
  • Weight (Lbs.) 396
